WTS a lightly used Ecler XLA 1600. Used less than 10 times. About 2 years old.
Kept in aircon room. Comes with travel hard case. Less than 10kg.
Selling $560.ono Contact via email - pro326@gmail.com
Personal warranty of 1 week
Make & Model: Ecler XLA-1600 Amplifier.
Description: The revolutionary XLA series allows DJs, small clubs and professional installers on a budget to benefit from the expansive premium features common throughout Ecler’s revered range of installation amplifiers.
The XLA 1600 is a low weight power amplifier, specially designed to technologically compete and beat retail market leaders. The low weight to high power ratio works in favour of mobile and bedroom DJs, who frequently need to move their kit from venue to venue.
The integrated crossover function, when activated, sends the low frequency band to channel 1 and the high frequency band to channel 2 (cross point at 150 Hz), making it easy and quick to set up a two-way channel configuration without the need of external processing.
The aesthetically pleasing design is also functional, and a critical part of the superlative performance. In the traditional 19” rack format (two units high), the grated façade not only keeps the unit light, but also offers an efficient system of progressive ventilation where air is taken in at the rear and thrown out the front, keeping the amp at optimum operating temperature.
Safety features include the easily accessible input attenuation controls, which are clearly adjustable on the front panel. There are also indicators for ‘Power On’, ‘Signal Presence’, ‘Clipping’, ‘Operating Mode’ (i.e. bridge), and ‘Crossover Activation’. Moreover, keeping the signal clean is the permanently enabled ‘anticlip circuit’.
Now powering a house party, small bar or club, or even just your home set-up is easier and more affordable than ever, but without the compromise of quality.
Main characteristics
• Ultra light technology (9.2 kg)
• Integrated crossover filter
• Variable fan speed system proportional to the internal amplifier temperature. Back to front ventilation.
• Rotary input attenuation controls in the front panel, easily accessible.
• LEDs of Power On and Stand By, Signal Present, Clip, Stereo/Bridge, Crossover activated and protection of activation.
• Effective protection system against short-circuit, overheating and DC signal presence, in order to avoid damage to the amplifier and the connected speakers.
• Integrated anti-clip circuit, always active.
• Mode selector: STEREO, PARALLEL and BRIDGE.
• Balanced inputs through XLR3 and 6.35 mm Jack stereo connections. Unbalanced RCA connections.
• Amplified outputs through binding posts and Speakon® connectors
Applications
• Small live sound systems
• Mobile applications
• Permanent installations
* POWER 20-20kHz 1% THD 4Ω Stereo 760 WRMS - 8Ω Stereo 450 WRMS - 8Ω Bridged 1520 WRMS
* Frequency Response (-1dB/-3dB) 10Hz/52kHz
* Crossover filter (-3dB) (CH1=LOW, CH2=HIGH) 150Hz/18dB oct.
* THD+Noise @ 1kHz Full Pwr. <0.1%
* S+N/N 20Hz-20kHz @ 1W/4Ω >85dB
* Damping factor 1kHz @ 8Ω >270
* Slew Rate ±30V/μs
* Input Connectors XLR3 & ¼” Jack balanced & RCA
* Input Sensitivity / Impedance 26/32dB/20kΩ Bal. 10kΩ Unbal
* Output connectors Speakon & Binding Posts
* Mains 230V 50/60Hz
* Dimensions 482.6x360x88mm
Kept in aircon room. Comes with travel hard case. Less than 10kg.
Selling $560.ono Contact via email - pro326@gmail.com
Personal warranty of 1 week
Make & Model: Ecler XLA-1600 Amplifier.
Description: The revolutionary XLA series allows DJs, small clubs and professional installers on a budget to benefit from the expansive premium features common throughout Ecler’s revered range of installation amplifiers.
The XLA 1600 is a low weight power amplifier, specially designed to technologically compete and beat retail market leaders. The low weight to high power ratio works in favour of mobile and bedroom DJs, who frequently need to move their kit from venue to venue.
The integrated crossover function, when activated, sends the low frequency band to channel 1 and the high frequency band to channel 2 (cross point at 150 Hz), making it easy and quick to set up a two-way channel configuration without the need of external processing.
The aesthetically pleasing design is also functional, and a critical part of the superlative performance. In the traditional 19” rack format (two units high), the grated façade not only keeps the unit light, but also offers an efficient system of progressive ventilation where air is taken in at the rear and thrown out the front, keeping the amp at optimum operating temperature.
Safety features include the easily accessible input attenuation controls, which are clearly adjustable on the front panel. There are also indicators for ‘Power On’, ‘Signal Presence’, ‘Clipping’, ‘Operating Mode’ (i.e. bridge), and ‘Crossover Activation’. Moreover, keeping the signal clean is the permanently enabled ‘anticlip circuit’.
Now powering a house party, small bar or club, or even just your home set-up is easier and more affordable than ever, but without the compromise of quality.
Main characteristics
• Ultra light technology (9.2 kg)
• Integrated crossover filter
• Variable fan speed system proportional to the internal amplifier temperature. Back to front ventilation.
• Rotary input attenuation controls in the front panel, easily accessible.
• LEDs of Power On and Stand By, Signal Present, Clip, Stereo/Bridge, Crossover activated and protection of activation.
• Effective protection system against short-circuit, overheating and DC signal presence, in order to avoid damage to the amplifier and the connected speakers.
• Integrated anti-clip circuit, always active.
• Mode selector: STEREO, PARALLEL and BRIDGE.
• Balanced inputs through XLR3 and 6.35 mm Jack stereo connections. Unbalanced RCA connections.
• Amplified outputs through binding posts and Speakon® connectors
Applications
• Small live sound systems
• Mobile applications
• Permanent installations
* POWER 20-20kHz 1% THD 4Ω Stereo 760 WRMS - 8Ω Stereo 450 WRMS - 8Ω Bridged 1520 WRMS
* Frequency Response (-1dB/-3dB) 10Hz/52kHz
* Crossover filter (-3dB) (CH1=LOW, CH2=HIGH) 150Hz/18dB oct.
* THD+Noise @ 1kHz Full Pwr. <0.1%
* S+N/N 20Hz-20kHz @ 1W/4Ω >85dB
* Damping factor 1kHz @ 8Ω >270
* Slew Rate ±30V/μs
* Input Connectors XLR3 & ¼” Jack balanced & RCA
* Input Sensitivity / Impedance 26/32dB/20kΩ Bal. 10kΩ Unbal
* Output connectors Speakon & Binding Posts
* Mains 230V 50/60Hz
* Dimensions 482.6x360x88mm
