CDA Pro-Audio is pleased to announce the new ATC SCM7
“…you will be amazed at its rhythmic and dynamic alacrity.” Hi-Fi Choice, May 2014. Group test winner!
Here is a review from Stereophile Magazine.
Features
- New ATC designed and built 25mm soft dome HF unit with precision alloy wave guide.
- 125mm ATC mid/bass unit with integral soft dome.
- In-house, hand-wound precision flat wire coil.
- 3Kg optimised motor assembly.
- Flat impedance curve allowing easy load for amplifiers.
- 6 year warranty.
Specifications
Drivers: HF 25mm Neodymium, Mid/LF 125mm
Matched Response: ±0.5dB
Frequency Response (-6dB): 60Hz-22kHz
Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
Sensitivity: 84dB @ 1W @ 1metre
Max SPL: 103dB
Recommended Power Amplifier: 75 to 300 Watts
Nominal Impedance: 8 Ohm
Crossover Frequency: 2.5kHz
Connectors: Binding Posts/4mm Plugs, bi-wire
Cabinet Dimensions (HxWxD): 300x174x215mm
Weight: 7.5kg
To arrange for a demonstration, please contact any of our current dealers:
Live Acoustics
Larry HiFi
Please feel free to contact us at CDA Pro-Audio should you have any questions.
Cheers
Joel C
Sales & Business Development
CDA Pro-Audio
www.cda-proaudio.com
Australia - New Zealand - Singapore - Thailand - Vietnam - China
(65) 9756 4007
Showroom:
10 Jalan Besar, #02-30
Sim Lim Tower
Singapore 208787
ATC Loudspeakers - CEDAR Audio - Lundahl Transformers - Maselec - Penny & Giles - Prism Sound
